CA4120

4 x 120W CLASS D 100V AMPLIFIER

Price: $1,500.00
Currently out of stock. Please enquire

Installation

Features


  • Rated power 4 x 120W
  • HPF filter switch 180Hz
  • Phoenix input and amplifier output connectors for easy installation
  • Phoenix input channel link connectors
  • Individual rear panel volume controls
  • Internal switch for amplifier stand by mode "ON" or "OFF"
  • Current limiter, overload, short circuit and thermal protection
  • Constant voltage 100V, speaker terminals
  • D Class

Cabinet Dimensions



Specifications


Rated Power 100V: 4 x 120W
Frequency Response (-3dB): 50Hz-15KHz
Signal to Noise Ratio: >90dB
Link Channels Phoenix Connectors:
 4
Line Output Phoenix Connectors: 4
Mains Power: 230V AC 50Hz
Line Input Phoenix Connectors: 4
Net Weight: 6.7Kg
Gross Weight: 8.0Kg
Dimensions (W x D x H): 483 x 380 x 88mm
Packaging Dimensions 1pcs/pack:
(W x D x H)		 590 x 490 x 180mm


Downloads

SCPA---CA4120-4240-4360-4480-Manual-Web.pdfSCPA---CA4120-4240-4360-4480-Manual-Web.pdf

File Size: 4MB

CA4120-Back-Pannel-Large-Image.pdfCA4120-Back-Pannel-Large-Image.pdf

File Size: 5MB

CA4120-Front-Pannel-Large-Image.pdfCA4120-Front-Pannel-Large-Image.pdf

File Size: 4MB

CA4120-Brochure.pdfCA4120-Brochure.pdf

File Size: 822kB
