CSW221
HIGH PERFORMANCE 2x21" 3600W SUBWOOFER
Installation
Features
- 3600W RMS power capacity (8 hours pink noise)
- Clean and deep reproduction
- Premium custom made European Driver
- Heavy braced, vibration free birch plywood cabinet
- Touring grade soft touch gloss-free black painting
Cabinet Dimensions
Specifications
| Power Capacity (50~15000Hz pink noise 8 hours): | 3600W RMS / 5000W Program |
|---|---|
| Nominal impedance: | 4ohms |
| Frequency response (-6dB half space, no EQ): | 30~1000Hz |
| Average Sensitivity: | 102dB/W/m |
| Maximum Calculated SPL @ 1m: | 137dB continuous / 143dB Peak |
| Nominal Directivity (-6dB): | Omidirectional in usable range |
| Recommended low cut filter: | 25Hz 24dB/oct |
| Low Frequency driver: |
Custom made 21″ CELTO Acoustique 4.5” / 115 Long Throw Die Cast Aluminum |
| Crossover: | No, only use in active mode with external electronic crossover |
| Flying hardware: | No |
| Connectors: | 2x NEUTRIK Speakon® NL4MP (1+/1- Input & Link, 2+/2- Link) |
| Pole mount: | 2 x 20mm thread Socket |
| Cabinet: | CNC made with tongue and grove assembly,all made with 18mm birch plywood |
| Finish: |
Black Textured Waterborne Coating Acoustic PU Foam behind Front Grill |
| Dimensions (W x D x H): | 588 x 1226 x 805mm |
| Packaging Dimensions 1pcs/pack: (W x D x H) |
688 x 1326 x 905mm |
| Net Weight: | 99Kg |
| Gross Weight: | 114Kg |
| Warranty: | 5 Years |
| Accessories: |
CSW221-SBAG (Padded Cover Bag) CPC-70 (Pole with Crank) SUBWHKIT100C (Castor Wheel Kit) |
