TF12
12 signal inputs (8 MIC inputs, 1 stereo analog input, 1 stereo USB/Bluetooth/PC sound card input). 8 signal outputs (main output L/R, 4 AUX, 1 set of stereo recording, Headphone
Features
-
3" high-definition color TFT LCD screen
-
IPad or Tablet software control
-
Faders 100mm electric intelligent control
-
12 balanced mic/line inputs
-
Input gain trim on all input channels
-
4-band input channels PEQ
-
4Aux sends on all input channels
- Built-in global Digital Effects sends on all input channels
- Built-in compressor, gates
-
Main L & R output master
-
Switchable +48V phantom power per channel
-
Pan on all input channels including effects
- Built-in WiFi
- USB or Bluetooth for replay and recording
-
Headphone jack for monitoring with PFL
Specifications
| Mono Inputs (balanced): | 7Mic (XLR)/Line (TRS) |
|---|---|
| Aux Sends (balanced): | 4 (XLS) |
| Main Out (balanced): | Left & Right (XLR) |
| Stereo Headphones: | 1 (TRS) |
| Mic Input Impedance: | 6.8Kohm |
| Line Input Impedance: | 20.6Kohm |
| Line Max Input Signal: | +4dBu (1.23V) |
| Main Output Max Level: | +26dBu (15.5V) |
| S/N Ratio (all channels assigned 0dB gain): | 95dB |
| Frequency Response: | 20Hz to 20kHz |
| Phantom Power: | +48V |
| Sample Frequency: | 48kHz |
| Effects: | 4 Professional Effects |
| Net Weight: | XXkg |
| Gross Weight: | XXkg |
| Dimensions (W x D x H): | XX0x XX3x XX0mm |
| Packaging Dimensions (W x D x H): | XX0 x XX0 x XX0mm |
| Warranty: | 2 Year |
