MU18Ba

HIGH POWER 500W POWERED FRONT-LOADED SINGLE 18" SUBWOOFER

Price: $1,788.00
Amount:

Installation

Features





  • High output SPL and sensitivity
  • One 18" high power low frequency driver with 100mm voice coil
  • Sensitivity 97dB, Max SPL 124dB
  • Built in power amplifier module
  • RMS 500W, Peak 2000W
  • Master volume control
  • Built in variable crossover 80Hz-250Hzhigh cut
  • Phase Switch
  • XLR input and output connector
  • Computer aided design to optimise frequency and phase response
  • Multi purpose cabinet design for FOH use
  • Suitable for use with any full range or mid/high speaker cabinets for extended low frequency, high quality music reproduction
  • Integral 35mm pole receptacle for mounting full range or mid/high speaker cabinets
  • Powder coated grill with foam backing
  • Durable Polyurethane textured paint

Cabinet Dimensions









Specifications





Transducers: Low Frequency: 18"

Frequency Response (-3dB): 40Hz-300Hz
Sensitivity (1W/1m): 97dB
Rated Power (RMS): 500W
Rated Impedance: 8ohm
SPL (1m): 124dB
Input Connectors:

1 x Combo 6.35/XLR Input, 1 x XLR Output

Net Weight: 43Kg
Gross Weight: 49Kg
Dimensions (W x D x H): 600 x 640 x 550mm
Packaging Dimensions 1pcs/pack:

(W x D x H)
750 x 710 x 670mm
Warranty:

5 Years

Downloads

MU18Ba.pdfMU18Ba.pdf

File Size: 580kB
